9 replies to this topic

[thager]

if anyone has pics if the rear drivetrain of transit or coaches, can you post them, im interseted in seeing how the rear engine/transmission are configured to the rear axle. thanks

[thager]

ok maby i need to a little clerer on my request, what im looking for is pics of the underside like if the bus was on a lift or on its side.

[OC Transpo 8238]

What's the purpose?

[thager]

i just want to see how the driveshafts go from the trans to the rear drive axle. just curious thats all.

[CR SD40-2]

same as any car or truck just only a smaller drive shaft thats all

[smallspy]

You mean something like this?

http://www.jalopyjou...61&d=1143422620

It's amazing what a quick search in Google will bring up...

Dan

[translink fan]

I have some pics of the rear compart and under of a D40LF in one of my flickr sets: http://www.flickr.co...57628383130563/

[thager]

thanks

smallspy, on 17 July 2012 - 04:44 PM, said:

You mean something like this?

http://www.jalopyjou...61&d=1143422620

It's amazing what a quick search in Google will bring up...

Dan

i tried searching , what keywords did you use ?

[VancouversLocalNerd]

That image shows an angle drive configuration, most modern buses are a little bit simpler (in basic design, not mechanically). Here's an image of the underside of a D40LF, transmission is mounted on the bottom behind the rear axle, a small driveshaft connect the two. Most newer buses use a similar setup.

 IMG_4386.jpg   1.58MB   23 downloads <- Click to enlarge

[thager]

cool thanks
